100V , 300mA , Silicon switching diode-1N4148WSD

● Total peak forward current: IF ≤ 300 mA ● Small plastic package suitable for surface mounted design ● Peak repetitive reverse voltage : 100V

Technical Info

Repetitive Reverse Voltage

100 V

Continuous Forward Current

0.3 A

Peak Surge Current

2 A , @ T = 1.0us

Reverse Recover Time

4 nS , IF = IR = 10mA,Irr = 0.1*IR, RL = 100Ω

Diode Forward Voltage

0.715 V , IF = 1mA

Junction Capacitance

4 pF , Vdc = 0V,F = 1MHZ

Configure

Common

Package

DFN1006-3L
